Snom m9 - 4 linje, SIP, IPv6,

Snom m9 je IP DECT telefon sljedeće generacije (CAT-iq) koji omogućava korisnicima slobodnu bežične komunikacije, zajedno sa brojnim naprednim funkcijama VoIP telefonije.
Snom M9 je idealan za profesionalno i privatno korištenje zbog kombinacije profesionalnih funkcija sa intuitivnim značajkama mobilnog svijeta. Snom M9 je savršen spoj mobilnosti i praktičnosti. Odlikuju ga brojne značajke kao što su hands-free način rada, identifikacija broja sa prikazom imena pozivatelja, prikaz broja i slike pozivatelja, te tipične značajke kao što su adresar, kalendar, kalkulator i alarm funkcija ..

Snom m9 više..

• Interference free DECT telephony
• 100+ hours standby time
• High interoperability
• Voice encryption
• snom OCS edition ready
• Wideband Audio
• IPv6 ready
• Intercom-, alarm- and calendar-function

Technical Data:

Display

• Color TFT Display (65,536 colors)
• Resolution 128x128 P ixel
• 5-step contrast adjustment
• Status indication of signal strength, alarm, “DND”, call diversion, battery status, MWI, loudspeaker
• Date & time (manual or auto synchronized)
• Caller I D with name and image
• National L anguage S upport

Measurement s

• Size: 125 x 50 x 20 mm
• Base station: 168 x 144 x 32 mm
• Charging cradle: 80 x 72 x 21 mm

Weight

• Handset (approx.): 98g
• Base station: 275g
• Charging cradle: 80g

Battery

• Li-Ion 3.7V

Power

• Charging cradle: 5.9V DC
• Base station: 5V DC

Keypad

• Illuminated
• 12 numeric keys
• 2 softkeys
• 5 navigation keys
• Key-barring
• Loudspeaker
• Volume adjustment
• 24-digit input
• Multiple input modes

User interface

• Emergency calls
• Call lists (missed, dialed, received)
• Address book (170 entries)
• Digital clock with automatic time synchronization
• Talktime indication
• Convenient and intuitive menu structure
• Polyphonic ringtones
• Handsfree mode
• Customizable wallpaper
• Screensaver
• Auto answer

Further functions

• USB interface
• Music-on-hold (only when connected to PBX)
• Call hold
• Call transfer
• Call redirection
• Caller lists
• Call Waiting I ndication (CWI)
• Message Waiting I ndication (MWI)
• Do Not Disturb (DND)
• RSS Feed Reader
• Missed calls indication
• 4 simultaneous VoIP calls
• Registration of up to 9 handsets
• Intercom (handset-to-handset calling without PBX)
• Calling line identification from address book
• Mailbox (PBX)
• VCARD 3.0 support
• Speed dial
• LDAP

Audio

• Wideband audio
• Voice E ncryption (SRTP)
• Mute function
• Volume adjustment – 6 steps
• Separate settings for a) handsfree and b) headset
• Ringer volume – 6 steps + O FF
• 2.5mm H eadset Jack
• Key-press tone – Click, DTMF and special sounds
• Acoustic warning for low battery status and charging

Codecs

• G.711, G .722, G .726, G .729

Voip

• Pre-configured P BX profiles
• IP v6 ready
• snom O CS edition ready
• RFC3261-compliant
• Digest and NTLM authentification
• DNS S RV (RFC3263),
• Offer/answer (RFC3264)
• Indication of incoming messages(MWI in accordance with RFC3265)
• DTMF (Inband, O utband, SIP I NFO)
• SIP configuration via base station or handset
• IPS /TLS

Installation

• Automatic software updates
• Automatic upload of settings via H TTP and TFTP
• Control LE Ds on base station for network activity, power and VoIP registration
• Reset key
• VLA N
• Standards: DECT, GAP
• Supports: DECT encryption
• Device diagnostics mode
• LL DP

Configuration

• Embedded web server
• Autoconfiguration via H TTP/HTTPS
• Embedded X.509 certificate
• TR-69/TR-111 for remote device management
• Over-the-air and US B firmware upgrade
